Position Indicator Gate Valve

Industrial valves and fittings dispatch fast — wear parts and complete machines quoted on request.

Gate Valves

Resilient and metal-seated gate valves, buried and specialty types for municipal and industrial water systems.

Browse Cryogenic Valves

Need the right valve for your duty?

Send the medium, DN, PN or Class, temperature and connection details. We return a selection proposal, the manufacturer's datasheet, a dimensional drawing, and a quotation with deviations listed against your specification.

Contact

Or email us directly: sales@kingnatrading.com

A dial indicator on an NRS valve: the stem turns inside the body where nobody can see it, and this adds a pointer and a scale on the bonnet so the wedge lift is read as a number instead of judged by how many turns the man remembers. On a network where valves are set to a partly-open position, that is the difference between a flow that can be balanced and one that is guessed at every shift. Retrofittable on a standard NRS body, gear or wrench nut operation, potable-water epoxy body.

General Specifications

IndicatorBonnet-mounted dial
ReadingExact disc position
MountingRetrofittable design
ServicePotable water
OperationManual gear / wrench nut
Pressure RatingPN10 / PN16
Max. Working Temperature0 – 80 °C (EPDM seat)

Materials & Coating

BodyDuctile iron, epoxy coated; duplex 2205 / 2507 available on request
SeatEPDM (standard)

Design Features

Why it mattersTurns 'open by feel' into a readable position

Applications

Utility networks Distribution chambers Inspection-critical lines
